| Item | Specifications |
| CPU |
All the B1/B2/B3 model use Intel@Celeron@ Processor N5100 4M Cache,Up to 2.8GHz, TDP 6W Intel® UHD Graphics(350-800Mhz) ,Support 4K 60Hz display AES-NI hardware support |
| RAM memory | Built-in DDR3 8GB /16GB Optional |
| Remarks: B1=4GB B2=8GB B3=16GB (RAM) | |
| Hard disk | Built in 16GB/128GB EMMC |
| Remarks: B1=16GB B2=128GB B3=128GB (EMMC) | |
| Brand | Gowin R86S |
| Extra storage | B2/B3 model Support 1*M.2 Nvme 2280 PCIE |
| +USB disk+TF Card | |
| ， | |
| pre-install Openwrt OS Support Windows,pfsense, Linux（Ubantu).All hardware tested with pfSense, untangle, OPNsense and other popular open-source software solutions | |
| Operation System | |
| Network Port | Built-in 3X 2.5GbE Intel I225-V Ethernet |
| I/O | 2*USB3.0+HDMI*1+TF*1+DC*1 port |
| Cooling Method | Fanless |
| Working Temp | 28-48℃ (In regular environment) |
| Power Supply | DC12V 4A (Support auto Power-On) |
| Size&Weight | 119*79*27.5mm Net Weight:0.7 lbs |
| Spare parts | AC adaptor,Users manual |
| Packing size | Inner Giftbox 21*12*6cm Outside Carton 24*15*8cm Gross Weight: 1.6 lbs 1pcs/box 20pcs/Carton |
| Item colors | Regular Color：Black,Grey OEM Colors：Orange， Green，Blue,Red |
| Leading time | 48 hours for samples, 20days for trial order(100-500pcs) |
| Warranty | 18months |
| GW-R86S-B3 | Intel@CeleronN5100 CPU+4GB Ram+16GB Storage |
| +128GB Storage+3*2.5g ethernet port | |
| +Support 1*M.2 2280 MVME(Extra parts need to pay) |
