| Item | Specifications |
| CPU |
The G1/G2 model use Intel@Celeron@Processor N5105 4M Cache,Up to 2.9GHz, TDP 10W The G3 model use Intel@Celeron@Processor N6005 4M Cache,Up to 3.3GHz, TDP 10W Intel® UHD Graphics(450-900Mhz) ,Support 4K 60Hz display AES-NI hardware support |
| RAM memory | Built-in DDR3 8GB /16GB Optional Remarks: G1=8GB G2=16GB G3=16GB |
| Hard disk | Built in 128GB EMMC |
| Brand | Gowin R86S |
| Extra storage | Support 1*M.2 2280 PCIE +USB disk+TF Card |
| Operation System | pre-install Openwrt OS，Support Windows,pfsense,Linux（Ubantu).All hardware tested with pfSense, untangle, OPNsense and other popular open-source software solutions |
| Network Port | Built-in 3X 2.5GbE Intel I225-V Ethernet+Dual-Port SFP+ 10Gbe Fiber Ethernet |
| I/O | 2*USB3.0+HDMI*1+TF*1+DC*1 port |
| Cooling Method | Built-in 2*mini fans+2*metal radiators |
| Working Temp | 28-52℃ (In regular environment) |
| Power Supply | DC12V 4A (Support auto Power-On) |
| Size&Weight | 119*79*39.5mm Net Weight:1.0 lbs Gross Weight: 1.9 lbs |
| Spare parts | AC adaptor,Users manual |
| Packing size | Inner Giftbox 21*12*6cm Outside Carton 24*15*8cm Gross Weight: 1.9 lbs 1pcs/box 20pcs/Carton |
| Item colors | Regular Color：Black,Grey OEM Colors：Orange，Green，Blue,Red |
| Leading time | 48 hours for samples, 20days for trial order(100-500pcs) |
| Certifications | CE/RoHs/FCC |
| Warranty | 18months |
| GW-R86S-G1 | Intel@CeleronN5105 CPU+8GB Ram+128GB Storage+3*2.5g ethernet port+Dual-Port SFP+ 10Gbe Fiber Ethernet Support 1*M.2 2280 MVME |
